ImageIR® c7300: Focus on the Essentials
For users focused on cost-effectiveness, InfraTec now offers cameras with predefined configurations as the Compact-Line. The ImageIR® c7300 is the ideal choice for cost-conscious users looking for a compact, high-performance infrared camera with cooled photon detector technology. The first new camera in the Compact-Line series offers high measurement precision for demanding tasks, while prioritizing cost efficiency over individually optimized camera performance.
The ImageIR® c7300 is particularly well-suited for continuous commercial use: Its heavy-duty, MWIR long-life cooler with an average service life of 28,000 hours enables reliable, cost-effective measurements in 24/7 operation. Compact size, a wide range of mounting options, and low weight make it easy to integrate the ImageIR® compact into systems, test benches, and automation solutions.
ImageIR® c7300: Well-equipped for Tasks in Industry, Research, and Monitoring
The integrated 5-position filter wheel provides a standard measurement range of (-10 … 1,500) °C, which can be optionally extended to 3,000 °C. Thus, the ImageIR® compact is suitable for a wide variety of applications in industry, research, and monitoring. A wide range of high-quality infrared lenses with fixed focal length is available to accommodate the size of the test objects and the specific details to be analyzed. The ImageIR® c7300 can be conveniently operated and configured via a web interface. Power is supplied via a wide-range power supply or via PoE.
A Wide Range of Interfaces for Easy Integration
When it comes to integration, the ImageIR® c7300 proves practical: On-camera calibration data enables an easy plug-and-play installation. The camera is equipped with interfaces for reliable and fast data transmission (GigE)be integrated as well as for software integration and control (GenICam / GigE Vision). In addition, the ImageIR® compact camera enables highly precise and repeatable output of internal trigger signals as well as processing of external trigger signals.
ImageIR® compact: Cooled Thermal Imaging Cameras for Cost-conscious Customers
With the ImageIR® compact cameras, InfraTec is expanding its portfolio of cooled infrared cameras with a series of models that consistently combine performance tailored to specific requirements, a compact design, and an attractive price-performance ratio. These cameras, including the new ImageIR® c7300, come with a predefined configuration focusing on the capabilities that are key to many measurement tasks: reliable radiometric temperature measurement, excellent image quality, high frame rates (snapshot image acquisition), and easy integration into existing processes.
